Recyclable: aluminium snapframe perimeter frame, PET poster cover, acrylic light panel
Next day delivery (unprinted)
Artwork and Print Service
Similar performance as the Edgelit XT but with the following cost saving differences:
- No built-in on/off switch.
- Lighter frame profiles but external appearance virtually identical.
- 3.5m long power cable with 3-pin plug.
- Double-sided units include hanging points for portrait and landscape (XT must be specified before manufacture).
- CE certificate supplied with each unit.
- Custom sizes* and colours available made to order (no minimum order quantity).
- Find out more about our Printed Backlit Poster Films.
Single Sided (for wall mounting):
| Poster Size | Display Area (mm) | O/A Dimensions (w x h x d mm) |
Weight (kg) | Availability | Order Code |
| A4 | 189 x 276 | 240 x 327 x 18 | 1.05 | Stocked item | BBLEDA4 |
| A3 | 276 x 399 | 327 x 450 x 18 | 1.45 | BBLEDA3 | |
| A2 | 399 x 573 | 450 x 624 x 18 | 2.5 | BBLEDA2 | |
| 20" x 30" | 487 x 741 | 538 x 792 x 18 | 3.3 | BBLEDA23 | |
| A1 | 573 x 820 | 624 x 871 x 18 | 4.5 | BBLEDA1 | |
| 30"x 40" | 741 x 995 | 792 x 1046 x 18 | 6.35 | BBLEDA34 | |
| A0 | 820 x 1168 | 871 x 1219 x 18 | 8.5 | BBLEDA0 |
*Max size 850 x 1200mm. Max perimeter 4000mm. Max short side 850mm. Max long side 1500mm
Double Sided (for suspending):
| Poster Size | Display Area (mm) | O/A Dimensions (w x h x d mm) |
Weight (kg) | Availability | Order Code |
| A4 | 189 x 276 | 240 x 327 x 30 | 1.28 | Made to order | BBDSLEDA4 |
| A3 | 276 x 399 | 327 x 450 x 30 | 2.09 | BBDSLEDA3 | |
| A2 | 399 x 573 | 450 x 624 x 30 | 3.67 | BBDSLEDA2 | |
| 20" x 30" | 487 x 741 | 538 x 792 x 30 | 5.3 | BBDSLEDA23 | |
| A1 | 573 x 820 | 624 x 871 x 30 | 7.01 | BBDSLEDA1 | |
| 30" x 40" | 741 x 995 | 792 x 1046 x 30 | 10.68 | BBDSLEDA34 | |
| A0 | 820 x 1168 | 871 x 1219 x 30 | 13.18 | BBDSLEDA0 |
*Max size 850 x 1200mm. Max perimeter 4000mm. Max short side 850mm. Max long side 1500mm
| Discontinued | No |
|---|---|
| Best Selling | No |
| Indoor/Outdoor | Indoor |
| Setting | Wall / Window Mounted |
| Display Type | Poster |
| Illumination | Illuminated |
Need help?
Click here to request assistance
Product Resources
Download templates & guidelines
Login to download:
-
- Specification sheets
- Instruction videos
- High resolution product images
- Artwork templates
- Instruction sheets
Best Buy LEDbox
See prices for this product when you log in
No account? Fill in the details below and we’ll send you a quote
